Description
SHELL SPIRAX S5 ATE 75W-90
Premium Synthetic Technology Transaxle & Automotive Gear Oil (API GL-4/GL-5) for High-Performance Vehicles, Manual Transmissions, Axles & Integrated Transaxle Systems
Product Description
Shell Spirax S5 ATE 75W-90 is a premium synthetic technology automotive gear lubricant specially developed for high-performance passenger car drivetrains, particularly transaxle transmissions where the gearbox and hypoid axle are combined in one housing and lubricated by the same fluid.
It is formulated with advanced synthetic base oils and a high-performance additive system to provide:
- Excellent gear protection
- Outstanding synchroniser performance
- High thermal and oxidation stability
- Reduced friction losses
- Extended lubricant life
It is suitable for heavily loaded manual transmissions, synchronised gearboxes, non-synchronised gearboxes, axle drives, and transaxle systems.
Features and Benefits
Outstanding Gear Protection
The advanced EP formulation provides:
- Excellent protection against gear wear
- Resistance to pitting and scuffing
- High load-carrying capacity
- Improved component durability
Excellent Synchromesh Performance
Designed for modern manual transmissions requiring controlled friction characteristics:
- Smooth gear engagement
- Improved shifting quality
- Reduced synchroniser wear
- Reliable transmission operation
Superior Thermal and Oxidation Stability
The synthetic technology provides:
- Excellent resistance to high-temperature degradation
- Reduced sludge and deposit formation
- Extended drain intervals
- Cleaner internal components
Improved Drivetrain Efficiency
The low-friction formulation helps provide:
- Reduced power losses
- Improved mechanical efficiency
- Lower operating temperatures
- Better fuel economy potential
Excellent Low-Temperature Performance
Provides:
- Fast oil circulation during cold starts
- Smooth shifting at low temperatures
- Reliable lubrication across a wide temperature range
Applications
Shell Spirax S5 ATE 75W-90 is recommended for:
Transaxle Systems
- Sports car transaxle transmissions
- Integrated gearbox and hypoid axle systems
- High-performance passenger vehicles
Manual Transmissions
- Synchronised manual gearboxes
- Non-synchronised gearboxes
Axle Applications
- Heavily loaded axle drives
- Final drives requiring SAE 75W-90 gear oil
Specifications & Approvals
Meets or exceeds:
- API GL-4
- API GL-5
- API MT-1
OEM approvals and recommendations include:
- MB-Approval 236.26
- Ferrari
- Getrag
Typical Physical Characteristics
| Property | Typical Value |
|---|---|
| Oil Type | Synthetic Technology Gear Oil |
| SAE Viscosity Grade | 75W-90 |
| Kinematic Viscosity @ 40°C | 81 mm²/s |
| Kinematic Viscosity @ 100°C | 14.9 mm²/s |
| Viscosity Index | 194 |
| Density @ 15°C | 879 kg/m³ |
| Flash Point (COC) | 205°C |
| Pour Point | -45°C |
| Operating Temperature Range | Approx. -40°C to +150°C |
Performance Characteristics
- Premium synthetic technology gear lubricant
- Excellent EP and anti-wear performance
- Outstanding synchroniser compatibility
- High shear stability
- Excellent oxidation resistance
- Reduced friction losses
- Extended service capability
- Excellent low-temperature performance
- Suitable for high-performance drivetrains
Storage & Handling
- Store in original sealed containers.
- Protect from moisture, dust, and contamination.
- Store in a cool, dry place away from direct sunlight.
- Keep containers tightly closed when not in use.
Health & Safety
When used as intended and handled according to good industrial hygiene practices, Shell Spirax S5 ATE 75W-90 presents minimal health risk.
Avoid prolonged skin contact and follow recommendations provided in the Safety Data Sheet (SDS).
