Description
Shell Omala S2 GX 150
Extreme-Pressure (EP) Industrial Gear Oil
Product Description
Shell Omala S2 GX is a line of premium EP (extreme pressure) mineral gear oils developed for heavy duty enclosed industrial gearboxes. They are formulated for steel-on-steel gear sets (spur, helical, planetary), especially under high loads, splash or forced circulation. The formulation provides excellent protection against wear, micro pitting, oxidation (thermal breakdown), corrosion, foaming, and also delivers good water separation.
Applications
-
Enclosed industrial gearboxes: spur, helical, planetary gear drives.
-
Systems with splash lubrication or forced circulation.
-
Bearings or other steel-on-steel components in gear oil systems.
Features & Benefits
| Feature | Benefit / Why it matters |
|---|---|
| High load carrying & EP performance | Protects gears under high torque or shock loads. |
| Micropitting protection | Helps avoid surface fatigue on gear tooth flanks, extending gear life. |
| Excellent oxidation stability | Leaves less sludge or varnish, meaning longer oil change intervals. |
| Water separation & corrosion resistance | Helps drain off water quickly, protects gears and bearings; avoids corrosion. |
| Low foam & good air release | Prevents issues from entrained air or foam that reduce film strength or cause vibration. |
| Seal & paint compatibility |
Reduces risk of leaks and protects painted surfaces in gear housings |
Specifications / Standards
-
ISO viscosity grades available: 68, 100, 150, 220, 320, 460, 680 (and possibly higher-viscosity ones)
-
Meets or is designed for:
• ISO 12925-1 CKC / CKD
• DIN 51517 Part 3 CLP
• AGMA EP 9005-F16
• AIST (US Steel) No. 224
Typical Physical Properties (Example for Omala S2 GX 150)
| Property | Test Method / Basis | Value (ISO VG 150 grade) |
|---|---|---|
| Viscosity @ 40 °C | ASTM / ISO standard | 150 mm²/s |
| Viscosity @ 100 °C | — | 15 mm²/s |
| Density @ 15 °C | — | 899 kg/m³ |
| Pour Point | — | -24 °C |
| Viscosity Index | 98 | |
| Flash Point | — | 240 °C |
