Description
Product Description
FUCHS TITAN SUPERGEAR SAE 75W-85 is an ultra high performance semi-synthetic multipurpose manual transmission gear oil specially developed for modern passenger car transmissions, synchronized manual gearboxes, light commercial vehicle transmissions, automotive gear systems, and applications requiring a low-viscosity SAE 75W-85 API GL-4 lubricant. Formulated with advanced base oil technology and high-performance additive chemistry, it provides smooth gear shifting, excellent wear protection, stable lubricating film under high loads, improved fuel efficiency, excellent seal compatibility, and reliable transmission performance across a wide operating temperature range.
Features and Benefits
Smooth Gear Shifting Performance
Optimised friction characteristics ensure smooth and reliable gear engagement, especially in modern synchronized manual transmissions.
Excellent Wear Protection
Provides effective protection for gears, bearings, synchronizers, and transmission components under normal and severe operating conditions.
Stable Lubricating Film Under High Loads
Maintains a strong protective oil film even under high mechanical loads, reducing component wear and extending transmission life.
Fuel Economy Benefits
The lower viscosity SAE 75W-85 formulation helps reduce internal friction losses compared with conventional higher-viscosity gear oils, contributing to improved transmission efficiency.
Excellent Seal Compatibility
Compatible with many elastomers and sealing materials used in modern automotive transmission systems.
Good Low Temperature Performance
Provides improved cold-flow characteristics for easier shifting and faster lubrication during cold starts.
Applications
FUCHS TITAN SUPERGEAR SAE 75W-85 is recommended for:
- Manual transmissions
- Synchronized gearboxes
- Passenger vehicles
- Light commercial vehicles
- Automotive transmission systems
- Modern fuel-efficient drivetrain applications
- Gearboxes requiring low-viscosity SAE 75W-85 fluid
Suitable for applications requiring:
- API GL-4
- SAE 75W-85 manual transmission oil
Specifications
- API GL-4
Typical Physical Characteristics
| Property | Typical Value | Test Method |
|---|---|---|
| SAE Grade | 75W-85 | SAE J306 |
| Type | Semi-Synthetic Gear Oil | — |
| Appearance | Clear Amber Fluid | Visual |
| Density @ 15°C | Approx. 0.86–0.88 g/cm³ | ASTM D4052 |
| Kinematic Viscosity @ 40°C | Approx. 70–90 mm²/s | ASTM D445 |
| Kinematic Viscosity @ 100°C | Approx. 12–14 mm²/s | ASTM D445 |
| Viscosity Index | Approx. 150+ | ASTM D2270 |
| Pour Point | Approx. ≤ -40°C | ASTM D97 |
| Flash Point | Approx. >200°C | ASTM D92 |
Typical values may vary within normal manufacturing tolerances.
Performance Characteristics
- Ultra high performance semi-synthetic technology
- Excellent manual transmission protection
- Smooth synchronizer operation
- Strong lubricating film under high loads
- Excellent anti-wear performance
- Reduced friction and improved efficiency
- Good oxidation stability
- Excellent compatibility with seals and transmission materials
- Reliable operation over a wide temperature range
Handling & Storage
Store in original sealed containers in a clean and dry environment. Protect from contamination by water, dust, and other lubricants.
Health & Safety
Refer to the latest Safety Data Sheet (SDS) for detailed information regarding handling, storage, transportation, and disposal.
