Product Description

FUCHS TITAN CARGO SAE 15W-40 is an ultra high performance (UHPD) diesel engine oil specially developed for modern commercial vehicle diesel engines, heavy-duty trucks, buses, construction equipment, mining machinery, agricultural equipment, and off-highway applications. It meets the latest API CK-4 performance requirements and combines advanced additive technology with a modern base oil formulation to provide excellent oxidation stability, outstanding shear stability, superior wear protection, excellent soot control, and extended engine durability under severe operating conditions.

The advanced formulation makes TITAN CARGO SAE 15W-40 particularly suitable for engines equipped with modern exhaust after-treatment systems including Diesel Particulate Filters (DPF), Diesel Oxidation Catalysts (DOC), Exhaust Gas Recirculation (EGR), Selective Catalytic Reduction (SCR), and turbocharging systems.

Features and Benefits

Excellent Oxidation Stability

Advanced antioxidant technology provides:

• Longer oil service life
• Reduced sludge and deposit formation
• Better protection during high-temperature operation
• Improved engine cleanliness

Outstanding Shear Stability

Maintains viscosity performance under severe mechanical stress, helping protect heavily loaded diesel engines during extended operation.

Superior Wear Protection

Provides reliable protection for:

• Cylinder liners
• Pistons and piston rings
• Camshafts
• Bearings
• Turbochargers
• Valve train components

under high-load commercial vehicle conditions.

Advanced Soot Control

The high-performance dispersant system prevents:

• Soot agglomeration
• Oil thickening
• Filter blockage
• Sludge formation

helping maintain engine efficiency and reliability.

Protection of Exhaust After-Treatment Systems

Low sulphated ash technology helps protect:

• DPF systems
• DOC catalysts
• SCR systems
• EGR components

and supports compliance with modern emission requirements.

Excellent High-Temperature Performance

Designed for severe-duty diesel engines operating under:

• Heavy loads
• Long-distance transport
• High ambient temperatures
• Continuous operation

Applications

FUCHS TITAN CARGO SAE 15W-40 is recommended for:

• Heavy-duty trucks
• Commercial vehicle fleets
• Buses and coaches
• Construction machinery
• Mining equipment
• Agricultural machinery
• Off-highway vehicles
• Diesel generator sets
• Turbocharged diesel engines
• Modern low-emission diesel engines

Suitable for engines equipped with:

• DPF
• DOC
• EGR
• SCR
• Two-stage turbocharging systems

Specifications

• ACEA E9
• ACEA E7
• API CK-4
• API CJ-4
• API SN
• CAT ECF-3
• JASO DH-2

Approvals

• CUMMINS CES 20086
• DETROIT DIESEL 93K222
• DEUTZ DQC III-18 LA
• FORD M2C171-F1
• MACK EOS-4.5
• MAN M 3775
• MB-Approval 228.31
• MTU DDC Type 2.1
• RENAULT RLD-3
• VOLVO VDS-4.5
• ALLISON TES-439

FUCHS Recommendations

• MAN M 3575
• RENAULT RLD-4

Typical Physical Characteristics

Typical values may vary within normal manufacturing tolerances.

Performance Characteristics

• Ultra high performance diesel engine oil
• API CK-4 heavy-duty formulation
• Excellent oxidation resistance
• Outstanding shear stability
• Superior soot handling capability
• Excellent wear protection
• DPF and SCR compatible
• Reduced sludge and deposit formation
• Long drain capability where approved
• Suitable for mixed commercial fleets

.

Handling & Storage

Store in original sealed containers in a clean and dry environment. Protect from contamination, moisture, and extreme temperatures.

Health & Safety

Refer to the latest Safety Data Sheet (SDS) before use. The product is not classified as hazardous according to Safe Work Australia GHS criteria.
